Asphalt Transport Tank
Item specifics
- Condition
- New
Review
Description
<iframe width="560" height="315" loading="lazy" src="https://www.youtube.com/embed/tbUW_DVtBq0" title="YouTube video player" frameborder="0" allow="accelerometer; autoplay; clipboard-write; encrypted-media; gyroscope; picture-in-picture" allowfullscreen></iframe>
Main Technical Description
IKOM manufactures long lasting and highly reliable asphalt tank trailers. Every asphalt trailer features special insulation as well as two high power burners to maintain the temperature of the contents. These high capacity trailers are the ideal equipment for asphalt transportation even over long distances.
Main Technical Parameter
Model |
ZZM9200GYY |
ZZM9250GYY |
ZZM9300GYY | ZZM9450GYY |
Dimension(mm) | 10000 × 2500 × 3350 | 10000 × 2500 × 3463 | 10000 × 2500 × 3550 | 12300 × 2500 × 3600 |
Asphalt tank(L) | 20000 | 25000 | 30000 | 45000 |
Flaming chamber | Φ 273mm × 2 L type | Φ 273mm × 2 L type | Φ 273mm × 2 L type | Φ 273mm × 2 L type |
Tire | Duble coins12R22.5 FUWU 13T Axis | |||
High temperature butterfly valve | 373H-16C | |||
Insulation layer | (50mm) Stainless steel + fiberglass insulation layer (50mm) | |||
Optional:
1. 2 units Italy Riello burner
2. Honda Generator for burner
3. Hydraulic system with hydraulic pump motor and asphalt pump for discharge
4. Heating transfer oil system for heating tank, pipe and asphalt pump
5. Power unit for driving asphalt pump
Product pictures
