Concrete Paver
Concrete Paver
Model
CP6000,CP8000

Review

Description

<iframe width="560" height="315" loading="lazy" src="https://www.youtube.com/embed/xyT-JZvQrMw" frameborder="0" allow="accelerometer; autoplay; encrypted-media; gyroscope; picture-in-picture" allowfullscreen></iframe>
Technology source and development

The technology of our slip-form concrete paver is from USA PRO-HOFF company. The machine travel by two tracks, with auto traveling and auto leveling control system, can finish concrete distribution, smooth, vibration, tamper, extrusion to road shape by one time, and this machine also can insert steel bars from middle and two sides of the road.
Main Technical Specification
Item
Unit
ZM-CP6000
ZM-CP8000
Paving Width
mm
3400-6000
4250-8000
Paving Thickness
mm
0-350
0-350
Paving Speed
m/min
0-10
0-10
Drive System
Full Hydraulic
Full Hydraulic
Running System
Track Shoe
Track Shoe
Engine Model
TAD620VE(Volvo)
TAD721VE(Volvo)
Engine Power
kw
145
195
Engine Speed
rpm
2300
2300
Pavement Evenness
mm/3m
3mm/3m
3mm/3m
Vibration Bar
High frequency & Hydraulic drive
High frequency & Hydraulic drive
Overall Size
mm
4020*7290*2770
4020*9290*2770
Machine Weight
t
22
25
Engine
Volvo water-cooled engine, powerful, high-torque reservation, low fuel consumption, emission in conformity with Europe environment.
Vibration Device
Super-high frequency, strong vibration, high density of top-side paving.
Auto Levelling System
Auto levelling and tracing systems ensures paving surface flatness and road straightness.
Centralized Lubrication
Centralized lubrication can auto charge lubrication grease to high-temperature and motive components, lengthen wear-out period effectively, greatly improve reliability of tamper and feeding.
Console
User-friendly interface with display, real-time monitoring for machine status.
Hydraulic Transmission
Hydraulic transmission for vibration bar, stepless frequency conversion to supply optimum frequency for all kinds of concrete.
Tamper Bar
Multi-segments and multi-bars design to ensure further compacting and mud extraction.
High Pressure Water Jet
To clean the machine effectively and to prevent concrete from hardening freezing on machine.
Control System
Micro-computer system with self-diagnostic capability.
Pictures on the jobsite
